Miele PW 413 - Technical Data and Safety Standards

Technical data
104
PW 413 machine data
Electrical connection
Voltage see data plate
Frequency see data plate
Total connected load see data plate
Current draw see data plate
Fuse rating see data plate
Heater rating see data plate
Installation dimensions
Casing width (without add-on components) 795 mm
Casing height (without add-on components) 1350 mm
Casing depth (without add-on components) 897 mm
Overall machine width 799 mm
Overall machine height 1352 mm
Overall machine depth 1010 mm
Minimum width of transport opening 805 mm
Minimum distance between wall and machine front 1350 mm
Weight and floor load
Net weight see installation plan
Max. floor load in operation see installation plan
Emissions data
Sound pressure level emission in workplace in accordance with EN ISO 11204/11203 <70 dB(A) re 20 μPa
Sound power level EN ISO 9614-2 <80 dB(A)
Product safety
Product safety standard
IEC 60335-1, IEC 60335-2-7
EN 60335-1, EN 50571
