Technical data

105

PW 418 machine data

Electrical connection

Voltage see data plate

Frequency see data plate

Total connected load see data plate

Current draw see data plate

Fuse rating see data plate

Heater rating see data plate

Installation dimensions

Casing width (without add-on components) 920 mm

Casing height (without add-on components) 1450 mm

Casing depth (without add-on components) 857 mm

Overall machine width 924 mm

Overall machine height 1452 mm

Overall machine depth 950 mm

Minimum width of transport opening 930 mm

Minimum distance between wall and machine front 1250 mm

Weight and floor load

Net weight see installation plan

Max. floor load in operation see installation plan

Emissions data

Sound pressure level emission in workplace in accordance with EN ISO 11204/11203 <70 dB(A) re 20 μPa

Sound power level EN ISO 9614-2 <80 dB(A)

Product safety

Product safety standard

IEC 60335-1, IEC 60335-2-7

EN 60335-1, EN 50571
