2. Bullet Camera
Figure 1-3
*Note:
1) The network camera provides a general I/O terminal block which is used to connect external
input/output devices. Please refer to the following instruction for the connection method.
Power Connector (DC 12V)
Alarm Input/ Output
RS-485 PTZ control
Ethernet Port
Lens
Video Output
Light Sensor
IR LED
Audio Output
Lens
Audio Input
