Milesight Network camera - Page 9

User Manual
8
Figure 1-4
3. Dome Camera
Figure 1-5
*Note:
1) The network camera provides a general I/O terminal block which is used to connect external
input/output devices. Please refer to the following instruction for the connection method.
Video Output
Power Connector (DC 12V)
Audio Output
Audio Input
RS-485 PTZ control
Alarm Input/ Output
Ethernet Port
