OM-273473 Page 48
LED Display
Message
Message
Type
LCD Display Message
LCD Solution
Message
LCD Error Log
Message
ERR PWR SRC ERROR Boost fault Cycle power on the power
source
Boost Fault Error
ERR PWR SRC ERROR Boost contactor error Cycle power on the power
source
Boost Contactor Error
ERR PWR SRC ERROR Boost CS1 current error Cycle power on the power
source
Boost CS1 Error
ERR PWR SRC ERROR Boost CS2 current error Cycle power on the power
source
Boost CS2 Error
ERR PWR SRC ERROR Boost CS3 current error Cycle power on the power
source
Boost CS3 Error
ERR PWR SRC ERROR Boost CS4 current error Cycle power on the power
source
Boost CS4 Error
ERR PWR SRC ERROR Boost current balance error Cycle power on the power
source
Boost Current Balance Error
ERR PWR SRC ERROR Boost overcurrent error Cycle power on the power
source
Boost Overcurrent Error
ERR PWR SRC ERROR Boost precharge error Cycle power on the power
source
Boost Precharge Error
ERR PWR SRC ERROR Boost bus balance error Cycle power on the power
source
Boost Bus Balance Error
ERR PWR SRC ERROR Boost bottom bus cap voltage high Cycle power on the power
source
Boost Bottom Bus Cap V High
ERR PWR SRC ERROR Boost top bus cap voltage high Cycle power on the power
source
Boost Top Bus Cap V High
ERR PWR SRC ERROR Invalid boost device configuration Cycle power on the power
source
Invalid Boost Config
ERR PWR SRC ERROR Boost −15V power supply out of regu-
lation
Cycle power on the power
source
Boost −15V Power Error
ERR PWR SRC ERROR Boost −24V power supply out of regu-
lation
Cycle power on the power
source
Boost −24V Power Error
ERR PWR SRC ERROR Boost +15V power supply out of regu-
lation
Cycle power on the power
source
Boost +15V Power Error
WRN VSNS LOS WARNING Lost volt sense lead feedback Inspect volt sense lead for
break
Vsense Fallback Warning
ERR UNKNOWN ERROR An unknown error has occurred Update software Unknown Error
