OM-291417 Page 17
F
Complete Parts List is available at www.MillerWelds.com
SECTION 4 – SPECIFICATIONS
4-1. Serial Number And Rating Label Location
The serial number for this product is located on the front. The rating information for this product is located on the back. Use rating label to deter-
mine input power requirements and/or rated output. For future reference, write serial number in space provided on back cover of this manual.
4-2. Software Licensing Agreement
The End User License Agreement and any third-party notices and terms and conditions pertaining to third-party software can be found at
https://www.millerwelds.com/eula and are incorporated by reference herein.
4-3. Information About Default Weld Parameters And Settings
NOTICE – Each welding application is unique. Although certain Miller Electric products are designed to determine and default to certain typical
welding parameters and settings based upon specific and relatively limited application variables input by the end user, such default settings are
for reference purposes only; and final weld results can be affected by other variables and application-specific circumstances. The appropriate-
ness of all parameters and settings should be evaluated and modified by the end user as necessary based upon application-specific require-
ments. The end user is solely responsible for selection and coordination of appropriate equipment, adoption or adjustment of default weld
parameters and settings, and ultimate quality and durability of all resultant welds. Miller Electric expressly disclaims any and all implied warran-
ties including any implied warranty of fitness for a particular purpose.
4-4. Weld, Power, And Carbureted Engine Specifications
F
This equipment will deliver rated output at an ambient air temperature up to 104°F (40°C).
Welding Mode Rated Welding Output
100% Duty Cycle at 40° C
Weld Output Range Maximum Open-Circuit Voltage
CC/DC
244A, 29.8V*
265A, 27V
20 – 265A
94.5V
CV/DC 260A, 27V*
265A, 27V
14 – 30V
Generator Power Rating Fuel Capacity Engine Operating Angle Fuel Type
Peak: 11 kVA/kW
Continuous: 9.5 kVA/kW Single Phase,
40A, 240 VAC,
20A, 120 VAC,
60 Hz Single Phase
11 gal (42 L) Tank
Kohler CH730
Air-Cooled, Two-Cyl-
inder, Four-Cycle,
23.5 HP
Gasoline Engine
20°
Gasoline up to 10%
Ethanol
*Meets NEMA and IEC Ratings
4-5. Environmental Specifications
A. IP Rating
IP Rating
IP23S
This equipment is designed for outdoor use. It may be stored, but is not intended to be used for welding outside during precipitation unless
sheltered.
B. Temperature Specifications
Operating Temperature Range* Storage/Transportation Temperature Range
–20 to 104°F (–29 to 40°C) –40 to 131°F (–40 to 55°C)
*Output is derated at temperatures above 104°F (40°C).
