Miller Bobcat 3 Phase User Manual

 A complete Parts List is available at www.MillerWelds.com
OM-4436 Page 16
5-3. Installing Exhaust Pipe
803 751 / Ref. 228 197-A
 Engine backfire can cause se-
vere burns or other injuries. Do
not point exhaust pipe toward
control panel. Keep away from
exhaust outlet.
 Point exhaust pipe in desired di-
rection but always away from front
panel and direction of travel.
 Be sure to tighten exhaust clamp
nuts. Exhaust clamp supplied with
muffler.
Tools Needed:
1/2 in
5-4. Connecting Or Replacing the Battery
804 802-A / 804 803-A / Ref. S-0756-D
3/8, 1/2 in
Tools Needed:
+
−
 Connect negative (−)
cable last.
+
−
Replacing The Battery
+
−
 Connect negative (−)
cable last.
+
−
Connecting The Battery
 Remove end panel to replace battery.
