OM-286308 Page 15
F
Complete Parts List is available at www.MillerWelds.com
5-5. Specifications
Specification Wireless Foot Control Wireless Hand Control 14–Pin Transceiver
Power Supply 4 — AA Batteries 4 — AA Batteries 10 — 35 Volts AC or DC
Rated Range
1
100 ft (30 m) 350 ft (107 m) N/A
Operating Humidity Range 0 — 97% 0 — 97% 0 — 97%
Operating Temperature Range
-18°F to +122°F
-25°C to +50°C
-18°F to +122°F
-25°C to +50°C
-18°F to +122°F
-25°C to +50°C
Radio Frequency 2.4 Ghz 2.4 Ghz 2.4 Ghz
RF Power 8 dBm 8 dBm 8 dBm
Antenna Internal Internal Internal
Dimensions
11.5 in. (293 mm) D
5.75 in. (146 mm) W
2.09 in. (153 mm) H
1.73 in. (387 g) w/Strap,
1.34 in. (34 mm) w/o
2.99 in. (76 mm) W
4.92 in. (125 mm) H
1.81 in. (46 mm) Dia
3.15 in. (80 mm) L
Weight 47 oz (1332 g) w/batteries 13.6 oz (387 g) w/batteries 2.56 oz (73 g)
FCC ID
QOQBGM13P
QOQMGM13P
2ASZL-301583
QOQBGM13P
QOQMGM13P
Canada IC
5123A-BGM13P
5123A-MGM13P
24958-301583
5123A-BGM13P
5123A-MGM13P
1
Not all applications are suitable for wireless communication. Rated range is approximate, and may vary depending on factors such as ob-
structions, frequency interference, transmission technology, and weather. The figures listed assumes ideal conditions are present.
5-6. Environmental Specifications
A. EU Ecodesign Information
OM-
1-1. Additional Safety Symbols And Definitions
Some symbols are found only on CE products.
Warning! Watch Out! There are possible hazards as shown by the symbols.
Safe1 2012 05
Do not discard product (where applicable) with general waste.
Reuse or recycle Waste Electrical and Electronic Equipment (WEEE) by disposing at a designated collection
facility.
Contact your local recycling office or your local distributor for further information.
Safe37 2017 04
Wear dry insulating gloves. Do not touch electrode with bare hand. Do not wear wet or damaged gloves.
Safe2 2017 04
Protect yourself from electric shock by insulating yourself from work and ground.
Safe3 2017 04
Protect yourself from electric shock by insulating yourself from work and ground.
Safe4 2017 04
Disconnect input plug or power before working on machine.
Safe5 2017 04
Keep your head out of the fumes.
Safe6 2017 04
Keep your head out of the fumes
Safe7 2017 04
Use forced ventilation or local exhaust to remove the fumes.
Safe8 2012 05
Use forced ventilation or local exhaust to remove the fumes.
Safe9 2012 05
Do not discard product (where applicable) with general waste.
Reuse or recycle Waste Electrical and Electronic Equipment (WEEE)
by disposing at a designated collection facility.
Contact your local recycling office or your local distributor for further
information.
Critical raw materials possibly present in indicative amounts higher than 1 gram at component level
Component Critical Raw Material
Printed circuit boards Baryte, Bismuth, Cobalt, Gallium, Germanium, Hafnium, Indium, Heavy Rare Earth, Light Rare
Earth, Niobium, Platinum Group Metals, Scandium, Silicon Metal, Tantalum, Vanadium
Plastic components Antimony, Baryte
Electrical and electronic components Antimony, Beryllium, Magnesium
Metal components Beryllium, Cobalt, Magnesium, Tungsten, Vanadium
Cables and cable assemblies Borate, Antimony, Baryte, Beryllium, Magnesium
Display panels Gallium, Indium, Heavy Rare Earth, Light Rare Earth,Niobium, Platinum Group Metals, Scandium
Batteries Fluorspar, Heavy Rare Earth, Light Rare Earth, Magnesium
