Miller FieldPro Remote CE - Page 33

OM-263 657 Page 27
B. Bad Setup
255 379-B
1 Welding Power Source
2 Weld Cable
3 Work Cable
4 Work Sense Lead
5 Remote
6 Workpiece
This arrangement is a bad setup. Clamps
for separate units should not be shared.
Weld cables should not be crossed.
