OM-263 657 Page 47
Description
Part
No.
Dia.
Mkgs.
Item
No.
Figure 9-2. Remote Parts Assembly
Model
Quantit
y
301176
1 +253680 Case, Molded (Including) 1... .............. .. ........................................
2 253723 Base, Remote 1... ............... .... ...............................................
3 253372 Pouch, Nylon 1000 Denier W/Velcro 1... ............... .... ............................
4 253671 Gasket, Remote 1... ............... .. ...............................................
5 253666 Bus Bar, LEM 1... ............... .. .................................................
6 HD1 191941 Transducer, Current 200A Module Supply V+/− 15V 1... ..... ..... .. ................
7 255046 Insert, Nyl 2... ............... .. .....................................................
8 255045 Cable, Volt Sense 15 ft w/Clamp & Term 1... ............... .. ..........................
9 242239 Conn, Tw Lk Insul Male(Dinse Type)1/0-2/0 Blk1... ............... ..
10 242240 Conn, Tw Lk Insul Fem (Dinse Type) 1/0-2/0 Blk1... ............... ..
11 PC1 255721 Circuit Card Assy 1... ..... ..... .. ..............................................
12 026947 Stand−Off, Insul .250−20 x 1.000 Lg x .312 Thd 2... ............... .. ....................
13 254969 Stand−Off, No 6−32 x 1.375 Lg .250 Hex Al Fem 2... ............... .. ...................
14 254883 Stud, Brass 1... ............... .. ...................................................
255326 Label, PipeWorx 350 Field Remote 1..................... .. ...............................
214521 Label, Warning Turn Off Power Before Opening 1..................... .. ....................
255253 Label, Warning Disconnect Input Power Before Servicing 1..................... .. ............
PLG12,.........
PLG21,
PLG14 255063 Housing Plug + Skts, (Service Kit) 3.... .. ................................
15 121276 Bushing, Strain Relief .450/.709 ID x 1.115 Mtg Hol 2... ............... .. .................
16 254257 Lead List, Large 2... ............... .. ...............................................
17 258463 Spacer, Nylon 010-32 x 2.500 x .500 Hex 4... ............... .. .........................
18 265458 Nameplate/Switch Membrane, Front Pnl Pwxfld Rmt (CE) 1... ............... .. ...........
19 265964 Circuit Card Assy, Frnt Pnl Pwxfld Ps/Rmt w/Pgm VRD 1... ............... .. .............
255133 Plugs, w/Leads (User Interface) 1..................... .. ..................................
255145 Cable, LEM Pipeworx 350 Field Remote 1..................... .. ..........................
255326 Label, Nameplate Pipeworx 350 Field Remote 1..................... .. .....................
255259 Label, Notice Only FieldPro Compatible 1..................... .. ...........................
258410 Card, Quick Reference Guide 1..................... .. ...................................
+When ordering a component originally displaying a precautionary label, the label should also be ordered.
BE SURE TO PROVIDE MODEL AND SERIAL NUMBER WHEN ORDERING REPLACEMENT PARTS.
