Miller PipePro 304 - Section 3 − Definitions; Symbol Definitions; Section 4 − Specifications; Weld, Power, and Engine Specifications

OM-492 Page 9
Return To Table Of Contents
SECTION 3 − DEFINITIONS
3-1. Symbol Definitions
Stop Engine
Fast
(Run, Weld/Power)
Fast/Slow
(Run/Idle)
Slow (Idle)
Start Engine Panel/Local Temperature Fuel
Engine Oil On
Check Valve
Clearance
Battery (Engine)
Engine
Read Operator’s
Manual
A
Amperes
V
Volts
MIG (GMAW),
Wire
Stick (SMAW) TIG (GTAW) Circuit Breaker
Foot Control Manual Control
Touch Start
(GTAW)
Pulsed
Positive Negative
Alternating Current
(AC)
Output
Time
h
Hours
s
Seconds
Protective Earth
(Ground)
Do not switch while
welding
14
Remote 14
Receptacle
Work Connection Glow Plug
Wire Feed
Electrode
Positive
Electrode Negative High Temperature
SECTION 4 − SPECIFICATIONS
4-1. Weld, Power, And Engine Specifications
Welding
Mode
Rated
Welding
Output
Maximum
Open-Circuit
Voltage
Amperage
Range In
CC Mode
Voltage
Range In
CV Mode
Generator
Power Rating
Fuel Capacity Engine
CC/DC
300 A, 32 V
,
60% duty
99
5 − 375 A
10 − 34 V
Single-Phase,
12 kVA/kW
100/50 A,
13 gal (49 L)
Tank
Kubota DH905
Water-Cooled,
Three-Cylinder,
CV/DC
60% duty
Cycle
99
5 − 375 A
10 − 34 V
100/50 A,
120/240 V AC,
60 Hz
13 gal (49 L)
Tank
Three-Cylinder,
Four-Cycle, 26 HP
Diesel Engine
