OM-492 Page 10
Return To Table Of Contents
4-2. Dimensions, Weights, and Operating Angles
Dimensions
A
B
Height 36 in (914 mm)
A
B
C
Width 24 in (610 mm)
C
 Do not exceed tilt angles or engine could
Depth 59 in (1499 mm)
D

Do not exceed tilt angles or engine could
be damaged or unit could tip.
Do not move or operate unit where it could
A 23-5/8 in (600 mm)
4 Holes
D
G
 Do not move or operate unit where it could
tip.
B 21-1/2 in (546 mm)
4 Holes
tip.
C 1 in (25 mm)
E
F
D 15-5/8 in (397 mm)
F
20
°
E 26-3/8 in (679 mm)
20
20°
F 58-3/4 in (1492 mm)
20°
20°
20°
G 13/32 in (10 mm) Dia.
20°
Weight
925 lb (420 kg)
800 426
Front Panel End
925 lb (420 kg)
800 426
Front Panel End
6 Minutes Welding 4 Minutes Resting
4-3. Duty Cycle And Overheating
Duty Cycle is percentage of 10 min-
utes that unit can weld at rated load
without overheating.
If unit overheats, output stops, a
Help message is displayed (see
Section 8-10), and cooling fan runs.
Wait fifteen minutes for unit to cool.
Reduce amperage or voltage, or
duty cycle before welding.
 Exceeding duty cycle can
damage unit and void
warranty.
60% Duty Cycle
Overheating
0
15
A or V
OR
Reduce Duty Cycle
Minutes
