OM-492 Page 15
Return To Table Of Contents
5-3. Adding Coolant To Radiator
Ref. 802 330-G
Stop engine and let cool.
Check coolant level according
to Section 5-2 before starting
this procedure.
If coolant level is below bottom of
radiator filler neck, add coolant as
follows:
1 Radiator Air Bleed Screw
Remove radiator air bleed screw.
Add coolant to radiator until coolant
is at bottom of filler neck. This en-
sures all air is purged from the sys-
tem.
Reinstall screw and radiator cap.
Check coolant level in recovery
tank (see Section 5-2).
Engine coolant is a mixture of water
and ethylene glycol base anti-
freeze. A solution of 50% antifreeze
and 50% water must be used in this
engine. Do not use 100% antifreeze
or severe damage will occur.
Tools Needed:
1
Full
Capacity
w/Overflow Tank
6.4 qt (6 L)
5-4. Connecting The Battery
Ref. 213 263-B / 802 330-G / Ref. S-0756-D
3/8, 1/2 in
Tools Needed:
+
−
Connect
negative (−)
cable last.
