Miller Syncrowave 350 LX - SECTION 4 - INSTALLATION; Selecting A Location

OM-356 Page 13
SECTION 4 − INSTALLATION
OR
Location And Airflow
Y Falling Unit Can Cause
Injury.
S Use lifting eye to lift unit only,
NOT running gear, gas
cylinders, or any other
accessories.
S Use equipment of adequate
capacity to lift and support
unit.
S If using lift forks to move unit,
be sure forks are long enough
to extend beyond opposite
side of unit.
1 Lifting Eye
2 Lifting Forks
Use lifting eye or lifting forks to
move unit.
If using lifting forks, extend forks
beyond opposite side of unit.
3 Rating Label
Use rating label to determine input
power needs.
4 Line Disconnect Device
Locate unit near correct input pow-
er supply.
Y Special installation may be
required where gasoline or
volatile liquids are present −
see NEC Article 511 or CEC
Section 20.
Y Be careful when placing or
moving unit over uneven
surfaces.
4-1. Selecting A Location
1
2
Movement
Ref. ST-117 264-C / ST-801 971-A
4
1
3
18 in (460
mm)
18 in (460
mm)
