OM-356 Page 30
5-13. Optional Sequence Controls
1 Sequence Selection Switch
See Section 5-14.
2 Start Time/Spot Time Control
See Section 5-15.
3 Start Current Control
See Section 5-15.
4 Crater Time Control
See Section 5-16.
5 Final Current Control
See Section 5-16.
Ref. ST-191 372
4
2
1
3
5
4
2
1
3
5
(CE Nameplate Only)
5-14. Sequence Selection Switch
1 Sequence Selection Switch
Switch controls Off, Start, Cra-
ter, Start/Crater, 4t, and Spot
functions. Place switch in de-
sired position.
Off− Place switch in Off position
when Sequence Selection func-
tions are not desired.
1
1
(CE Nameplate Only)
To Next Page
