Installation
15
Installation of the Tygon® Tubing
ATTENTION
Do not use any white tape on the threads of the Barbed Fitting. An O-ring is
located inside the POU Dispenser to ensure water tightness between the threads
of the POU Dispenser and the Barbed Fitting.
A
• Locate the clear Tygon Tubing and the Barbed Fitting from the
Accessories Bag.
• Screw the Barbed Fitting onto the bottom end of the POU
Dispenser (A).
B
• Push one end of the Tygon Tubing onto the end of the
Barbed Fitting (B).
Place the other end of the Tygon Tubing in a sink.
To Next Page
