SECTION 6 - PARTS
6.1 GENERAL
1. This section gives information regarding
replaceable components.
6.2 ILLUSTRATED PARTS LIST
1. Figure and Item Number Column
a) The item numbers shown in the detailed
parts list correspond to the item numbers
appearing on the exploded view illustration.
To nd an unknown part number, locate the
part on the illustration and note the item
number. Look for the item number on the
detailed parts list. The part number is on the
same line. A dash (-) precedes non-illustrated
item numbers.
2. Description Column
a) The name of the item is in the description
column.
3. Part Number Column
a) The supplier’s part number is listed in the part
number column.
4. Material/SPM Column
a) The material used to manufacture the part is
listed in the material/SPM column.
b) The strokes per minute is listed for all worm
and shaft assemblies in the material/SPM
column.
5. Quantity Column
a) The numbers appearing in the quantity
column are the total quantity of the listed part
required in its immediate assembly.
Refer to table numbers ( 6.3 to 6.23 ) for the above
Parts List information.
