Milton Roy mRoy A - Electronic Capacity Control Mounting (Figure 23)

71 Installation, Operations & Maintenance Manual
API Flange Mount IEC 90 B5
6.20 ELECTRONIC CAPACITY CONTROL MOUNTING (FIGURE 23)
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
140
Plug, Adapter- 1-7/16 and 7/8 Plunger
1-1/4 NPT
243-0045-030
1
Plug, Adapter- 19/32 Plunger, 3/4 NPT 243-0045-010
1
170
Sleeve, Threaded Mroy B ECC 243-0059-051
1
180
Screw, Socket Set- 6-32NCx1/4 405-0039-035
1
190
Decal, Capacity 253-0026-062
1
200 Ring, Calibration 253-0025-062 Aluminum 1
210
Knob, Capacity Adjust 255-0036-077 Acetal
1
213
Bearing, Control Spool 237-0075-052
1
217
Washer , Thrust - 1/2" 404-0147-051 Steel
1
220
Clip, E Ring - External 404-9983-151
1
810
Coupling , Drive 252-0120-077
1
820
Lock-Washer , Internal Tooth- 8 404-0104-082 Zinc Plated
2
830
Screw, Pan Head- 8-32NC x 1/2 405-0179-073 18-8 ss
2
840
Bracket , Mounting 204-0148-006 Steel
1
850
Stud , Mounting 232-0033-006
1
860
Nut, Serrated Flange- 1/4-20NC 405-0323-036 Zinc Plated
1
880
Screw, Socket Head - 5116-18 x 5/8 405-0157-024 Steel
1
880
Bolt, Tri-Groove - 5/16 x 3/4 L 405-0336-011
1
900
Actuator, Mroy Per Spec
1
910 Shaft, Drive 268-0053-077 Acetal 1
- Parts Not Illustrated
Parts Continued Next Page
690
Seal, Oil 408-9997-011
1
700
Spring , Finger 403-0121-009
1
- Lock-Washer , Spring - 3/8" 404-0041 -022 18-8 ss 4
- Nut, Hex - 3/8-16NC 405-0066-012 18-8 ss 4
710
Adapter, Motor- IEC 80 85 607-20388-001
1
780
Coupling Assembly- 5/8 x 24mm 30459
1
790 Screw, Hex Head - 3/8-16 x 1-1/4 405-0018-136 Zinc Plated 4
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
mRoy B MOTOR MOUNTS (FIGURES 17 & 18)
