Milton Roy mRoy A - Parts Common to Metallic Liquid End Models mRoy A

48Installation, Operations & Maintenance Manual
6.4 PARTS COMMON TO METALLIC LIQUID END MODELS mRoy A (FIGURES 19 & 20)
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
280 Contour Plate–Oil Side - 3-1/2” 298-0061-016 316 SS 1
285
Contour Plate-Process Side, Also
Used With Double Non-Contacting
Diaphragms)
298-0061-016 316SS 1
298-0061-028 Alloy 20 1
298-0061-030 Alloy C-22
1
460 O-Ring, Discharge Check Valve Cap 54436 Viton 1
510
Cartridge, Discharge Assembly 54157 316SS 1
54295 Alloy 20 1
54302 Alloy C-22
1
Cartridge, Discharge Assembly BSP
Vertical
54354 316SS 1
54355 Alloy 20 1
54356 Alloy C-22 1
Cartridge, Discharge Assembly BSP
Horizontal
54626 316SS 1
54627 Alloy 20 1
54628 Alloy C-22 1
520 Nut, Locking, Check Valve 209-0020-014 Stainless Steel 1
530
Back-up Ring, Spiral, Check Valve
Lock Nut
408-0073-141 PTFE
2
540 O-Ring, Check Valve Lock Nut 408-0068-065 FKM (VITON) 2
600
Cartridge, Suction Assembly (Double
Ball) 1/2” NPT Connection, (Except
Model “RP”)
221-0896-216 316SS 1
221-0896-228 Alloy 20 1
221-0896-230 Alloy C-22 1
Cartridge Suction BSP 54304 316 SS 1
54306 Alloy 20 1
54308 Hast C-22 1
-
Bushing, Reducing - 1/2” x 3/8”, Used
To Install New Suction Check Valve to
402-0001-045 316SS 1
402-0001-049 Alloy 20
1
- Parts Not Illustrated
Parts Continued Next Page
