45 Installation, Operations & Maintenance Manual
Figure 23. mRoy A and B Actuator (DWG(s) 999-2009-0008 and 999-2009-0007)
ELECTRONIC CAPACITY CONTROL
PNEUMATIC CAPACITY CONTROL
ECC, VIEW A-A
COUPLING ASSEMBLY
