Milton Roy mRoy A - Basic Parts List for Drive Models mRoy B

65 Installation, Operations & Maintenance Manual
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
10
Housing, Main Simplex 19/32” 54076 1
Housing, Main Duplex 19/32” 54074 1
Housing, Main Simplex 7/8” 54077 1
Housing, Main Duplex 7/8” 54079 1
Housing, Main Simplex 1 7/16” 54078 1
Housing, Main Duplex 1 7/16” 54080 1
20 Cup, Race 409-0066-020 Steel 1
30 Poppet, Relief Valve 212-0057-074 Nylon 1
40 Spring, Relief Valve 280-0046-541 Steel 1
50 Adjusting Screw, Relief Valve 256-0037-051 Brass 1
60 Plug - 1/4” NPT, Sq. Head 402-0009-111 1
90
Plunger, 19/32 22714 1
Plunger, 7/8 22716 1
Plunger, 1-7/16 22715 1
100 Rod, Connecting 214-0013-162 Aluminum 1
110 Pin, Dowel 5/8x1-1/2 401-0028-031 Steel 1
130
Gear Shaft 268-0030-006 Simplex, Steel 1
Gear Shaft 268-0022-006 Duplex, Steel 1
140
Plug, 1-1/4 NPT, Socket Hex Head 402-0095-076 1
Plug, 3/4 NPT, Socket Hex Head,
Models
402-0095-056 1
150 O-Ring, Parker 2-113, Control Spool 408-0068-032 Urethane 1
160 Control Spool 268-0049-006 Steel 1
170 Sleeve, Threaded, Mroy B ECC 243-0059-051 1
6.15 BASIC PARTS LIST FOR DRIVE MODELS mRoy B (FIGURES 17 & 18)
- Parts Not Illustrated
Parts Continued Next Page
