Milton Roy mRoy A - Double Diaphragm Parts for Metallic Liquid End

73 Installation, Operations & Maintenance Manual
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
280
Contour Plate - Oil Side 298-0012-006
285
Contour Plate - Process Side 298-0016-016 316 ss 1
298-0016-028 Alloy 20 1
298-0016-030 Alloy C-22 1
290
Diaphragm - 5.230 Dia. 298-0013-075 PTFE
2
292 Intermediate Chamber 20539 316 ss 1
328
Oil, Vegetable 40104 105-115 ml
(3.6-3.9 oz)
350 Screw, Hex Head- 7/16-14 x 2 1/2 405-0019-181 Steel 8
355 Screw, Hex Head- 7/16-14 x 3 3/4 40894 Steel 2
601 Plug, Pipe- 3/8" Threaded 402-0011-033 316 ss 1
602 Plug, Pipe- 1/8" Threaded 402-0011-013 316 ss 1
6.22 DOUBLE DIAPHRAGM PARTS FOR METALLIC LIQUID END (FIGURE 26)
- Parts Not Illustrated
Parts Continued Next Page
SIMPLEX LEAK DETECTOR PARTS- GAUGE & NEMA SWITCH (FIGURE 25)
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
290 Diaphragm, 5.230 Dia. L & R plunger 298-0013-075 PTFE 2
Diaphragm, 3.390 Dia. K plunger 298-0015-075 PTFE 2
300 Ring Assembly, Intermediate 219-0089-116 316 ss 1
Ring Assembly , Intermediate 179-1260-116 316 ss 1
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
