Milton Roy mRoy A - mRoy A: E & F Plastic Liquid End Parts

52Installation, Operations & Maintenance Manual
Parts Included
O-Ring - 3/8 x 3/32 225-0032-675 PTFE 2
Ball Stop 20289 PVC 2
Seat 20290 PVC 2
Ball, 3/8 Ad995 407-0015-111 Ceramic
2
Body, Cartridge 20288 PVC
1
495
Discharge Assembly, NPT 20302 PVC 1
Discharge Assembly, BSP 54364 PVC 1
Parts Included
O-Ring - 3/8 x 3/32 225-0032-675 PTFE 2
Ball Stop 20289 PVC 2
Seat 20290 PVC 2
Ball, 3/8 Ad995 407-0015-111 Ceramic 2
Body, Cartridge 20291 PVC 1
- Parts Not Illustrated
Parts Continued Next Page
MODEL mRoy A: E & F PLASTIC LIQUID END PARTS (FIGURE 19)
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
280
Contour Plate 298-0007-016 316 SS
1
281 Spring Pin 4010001041 1
290 Diaphragm 5” 298-0005-275 PTFE 1
330 Head 53961 PVC 1
340 Plate, Back-Up 54320 304 SS 1
350 Screw, Hex Head - 5/16-18 x 2-1/4 54441 18-8 SS 8
365 Fastprime Valve 48848 PVC 1
470
Check Valve Assembly, Suction NPT 49163 PVC
1
Check Valve Assembly, Suction BSP 54383 PVC
1
480
Check Valve Assembly Discharge
NPT
49243 PVC
1
Check Valve Assembly, Discharge
BSP
54375 PVC
1
6.9 MODEL mRoy A: C & D PLASTIC LIQUID END PARTS (FIGURE 19)
