59Installation, Operations & Maintenance Manual
- Parts Not Illustrated
Parts Continued Next Page
380 Bracket 204-0199-006 Steel 1
390 Lock-Washer, Spring - 5/16 404-0040-028 Zinc Plated 3
400 Nut, Hex - 5/16-18nc 405-0065-013 18-8 SS 3
1150
Check Valve - 1/8tube, 1/3 PSI 40065 316 SS
1
1160
Gage, Press - 0-400psi, Dual Flange
Mount
40066
1
Gage, Press - 1000psi, Dual Flange Mount 40176
1
1170 Adapter, Red - 1/4f x 1/8m, NPT 40067 316 SS 1
1180 Tee, Branch - 1/8NPTf x 1/8 tube 40060 316 SS 1
1190 Tee, - 1/8npt Female 40062 316 SS 1
1191 Tee, - 1/8npt Female 40062 316 SS 1
1200 Tube Conn.- 1/8 Tube x 1/8 NPT 40061 316 SS 1
1201 Tube Conn.- 1/8 Tube x 1/8 NPT 40061 316 SS 2
1210 Valve, Bleed - 1/8 NPT 40063 316 SS 1
1220 Screw, Pan Head - 4-40 x 1/2 405-0263-050 Zinc Plated 3
1230 Lock-Washer, Spring #4 404-0095-023 18-8 SS 3
1240 Nut, Hex - 4-40nc 405-0182-012 18.8 SS 3
1250
Switch, Pressure, Nema 4 - 5-30 PSI 406-0388-001
1
1250
Switch, Pressure, Nema 7 - 5-30 PSI 406-0389-001
1
1260 Nipple, Red Hex - 1/2x1/8, NPT 40064 316 SS 1
1270 Screw, Hex Head - 1/4-20x3/4 405-0016-095 18-8 SS 2
1280 Lock-Washer, Spring - 1/4 404-0039-022 18.8 SS 2
1290 Nut, Hex - 1/4-20nc 405-0064-012 18.8 SS 2
1300
Tubing, Pump To Gauge (formed) 249-0137-116
1
Tube - 1/8 od x 0.035 wall 402-0502-993 316 SS
12 in.
1320
Tubing, Gauge To Switch Nema 4 249-0136-016
1
Tubing, Gauge To Switch Nema 7 249-0138-016
1
Tubing, - 1/8 od x 0.035 wall 402-0502-993 316 SS
20 in.
1440
Leak Detector Instruction Manual 339-0036-000
1
1470
Mineral Oil (available at drug stores)
SIMPLEX LEAK DETECTION PARTS, FIGURE 22 (DOUBLE QUANTITIES FOR DUPLEX PUMPS)
