67 Installation, Operations & Maintenance Manual
- Parts Not Illustrated
Parts Continued Next Page
LIQUID END mRoy L,R (FIGURE 24)
330 Head, Diaphragm 54184 316 SS 1
54284 Alloy 20 1
-
Contour Plate - Process Side
201-0395-000 1
201-0428-000 1
370
Screw, Hex Head - 5/16-18 x 1-1/2
Gr5
405-0017-149 Steel 3
390 Lock-Washer, Spring - 5/16 404-0040-028 Zinc Plated 3
460 O-Ring, Discharge Check Valve Cap 408-0068-043 PTFE 1
510
Check Valve Assembly, Discharge NPT 54345 316 SS 1
54346 Alloy 20 1
54413 Hast C22 1
Check Valve Assembly, Discharge BSP 54359 316 SS 1
54360 Alloy 20 1
54415 Hast C-22 1
Check Valve Assembly, Discharge
(Slurry Applications)
22077 316SS 1
520 Nut, Lock
209-0021-017 416 SS 1
530 Back Up Ring, Spiral
408-0073-221 PTFE 1
540
O-Ring, Check Valve locking Nut - 3- 916,
1.171 x 0.116
408-9998-151 VITON 1
600
Check Valve Assembly, Suction NPT 221-0154-016 316 SS 1
221-0154-028 Alloy 20 1
30578 Hast C22 1
Check Valve Assembly, Suction BSP 54363 316 SS 1
54366 Alloy 20 1
54417 Hast C-22 1
Check Valve Assembly, Suction
(Slurry Applic)ation
22078 316SS 1
To Next Page
