4.2.9 PEN PRESSURE
1
2
3
4
5
6
7
8
6. Carry out each adjustment by up to 350 g following the
methods described above. (60, 100, 200, 350g)
7. Check the pen pressure using the tension gauge as necessary.
[FUNCTION]: Indicates the pen pressure
8. Check the pen pressure (10-350g) at appropriate pressure levels
before completing all the adjustments. (in 2 g steps)
[]/[]: Selects a pen pressure level
[END]: Completes
#PEN PRESSURE
60g =25
#PEN PRESSURE
100g =25
#PEN PRESSURE
200g =25
#PEN PRESSURE
350g =25
#PEN PRESSURE
20g=20
#PEN PRESSURE
30g=22
R.1.1
Maintenance Manual > Adjustment Items > Adjustment Function > PEN PRESSURE
