5.1.26 P.1

R.1.0

Maintenance Manual > Test Items > Test Function > LINEAR ENCODER

Model CJV30/TPC Issued 2008.08.04 Revised F/W ver. 1.00 Remark

1.0

Rev.

5.1.26 LINEAR ENCODER

 Function

Linear encoder scale and linear sensor are tested.

Move a carriage by the designated distance (3 reciprocations) to display the difference between linear encoder value

and Y-axis motor encoder value. If an error arises during the operation, discontinue the test.

Moving distance: 100 mm – Maximum actual operation limit (unit: 100 mm)

LCD display is as follows:

(M*: Y-axis motor encoder, E*: linear encoder)

• Moving distance : M=****.* E=****.* (unit: 0.1 mm)

• Difference in encoder values between before and after moving

: Mc=****.* Ec=****.* (unit: 0.1 mm)

• Encoder values before movement : Ms=***** Es=*****

• Encoder values after movement : Mm=***** Em=*****

• Encoder values after having moved by designated distance

: Mr=***** Er=*****

Be careful about the carriage which moves in high speed to execute the scan.
