Maintenance Manual > Operation Flow > Print Mode > MAINTENANCE
Model CJV30/TPC Issued 2008.08.04 Revised 2008.09.17 F/W ver. 1.20 Remark
1.1
Rev.
8.2.3 MAINTENANCE
CR.MAINTENANCE
COMPLETED :ent
To LOCAL mode after
completion of initial operation
FUNCTION
MAINTENANCE <ENT>
[FUNCTION],
[] / []
ST.MAINTENANCE
CARRIAGE OUT <ent>
ST.MAINTENANCE
COMPLETED :ent
MAINTENANCE
ST.MAINTENANCE <ent>
To LOCAL mode after
completion of initial operation
ST.MAINTENANCE
WIPER REPLACE <ent>
ST.MAINTENANCE
COMPLETED :ent
To LOCAL mode after
completion of initial operation
[FUNCTION],
[] / []
CR.MAINTENANCE
CARRIAGE OUT :ent
MAINTENANCE
CR.MAINTENANCE <ent>
[FUNCTION],
[] / []
ST.MAINTENANCE
NOZZLE WASH <ent>
WIPER CLEANING
COMPLETED(NEXT) :ent
[FUNCTION],
[] / []
Fill the liqid.
COMPLETED(NEXT) :ent
ST.MAINTENANCE
LEAVING TIME :1min
To LOCAL mode after a
lapse of preset time
ST.MAINTENANCE
PUMP TUBE WASH <ent>
ST.MAINTENANCE
COMPLETED :ent
To LOCAL mode after
completion of initial operation
[FUNCTION],
[] / []
ST.MAINTENANCE
COSTODY WASH <ent>
WIPER CLEANING
COMPLETED(NEXT) :ent
[FUNCTION],
[] / []
Fill the liqid.
COMPLETED(NEXT) :ent
ST.MAINTENANCE
LEAVING TIME :1min
To LOCAL mode after a
lapse of preset time
[FUNCTION]: Open/close valves
ST.MAINTENANCE
COMPLETED :ent
To LOCAL mode after
completion of initial operation
[FUNCTION],
[] / []
HD.MAINTENANCE
FILL UP INK <ent>
FILLING UP
00:00
MAINTENANCE
HD.MAINTENANCE <ent>
HD.MAINTENANCE
DISCHARGE&WASH <ent>
[FUNCTION],
[] / []
Remove:InkCartridges
MMCCYYKK
 DISCHARGE 
00:00
[FUNCTION],
[] / []
Set:WashingCartridges
12345678
 ABSORPTION 
00:00
Remove:Cartridges
12345678
 DISCHARGE 
00:00
Set:WashingCartridges
12345678
 ABSORPTION 
00:00
Remove:Cartridges
12345678
 DISCHARGE 
00:00
SELECT:
END< >Re-WASH
Maint.WashLiquid
END< >DISCHARGE
Remove:Maint.Wash  DISCHARGE 
00:00
[FUNCTION]: Open/close valves
CR.MAINTENANCE
Remove the cover: ent
Remove maintenance
cover.
