MIMAKI CJV30 Series User Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
8.1.3 P.1
1
2
3
4
5
6
7
8
R.1.0
Maintenance Manual > Operation Flow > Basic Operation > Media Detection
Model CJV30/TPC Issued 2008.08.04 Revised F/W ver. 1.00 Remark
1.0
Rev.
8.1.3 Media Detection
Lever down
<LOCAL.  > [#01]
 PINCH ROLLER 
PINCH ROLLER:No.6to1
>PRINT [MMMMMMM]
CUT [H_____H]
MEDIA SELECT
ROLL< >LEAF
DETECTING MEDIA NOW
PLEASE WAIT
 MEDIA 
Y=1000 X= 
Input of MediaLength
MEDIA LENGTH = 50.0m




[ENTER]: To the next screen
[]: to 
[ENTER]: Displays a screen according
to  and  settings.
[END]: To the previous screen
[END]/[]/[]:
[]: to 
When detection has
been completed Displayed momentarily
To <LOCAL> when MEDIA
RESIDUAL= ON

MIMAKI CJV30 Series Specifications

General

Cutting Function	Yes
Interface	USB 2.0, Ethernet
Power Supply	AC 100-240 V, 50/60 Hz
Print Head	Piezoelectric Inkjet
Resolution	1440 dpi
Print Resolution	Maximum 1440 dpi
Printing Technology	Solvent Inkjet
Print Speed	Up to 17.5 m²/h
Ink Type	Solvent Ink
Ink Colors	CMYK, White
Maximum Print Width	1610 mm (CJV30-160 model)
Media Width	1372 mm (54 inches)
Media Thickness	Maximum 1.0 mm
Cutting Force	500 g
Weight	180 kg (CJV30-160 model)
