MIMAKI CJV30 Series - Page 246

© 2009 MIMAKI ENGINEERING CO.,LTD.
6.5.16 P.2
6.5.16 Detector Assy, I/C, Y
1
2
3
4
5
6
7
8
3. Remove the detector assy, I/C, Y from the cartridge guide.
4. Reverse the disassembly procedure for reassembly.
Near End Sensor
Exist/non-exist Sensor
R.1.0
Maintenance Manual > Disassembly and Reassembly > Electrical Parts > Detector Assy, I/C, Y
Model CJV30/TPC Issued 2008.08.04 Revised F/W ver. 1.00 Remark
1.0
Rev.
