© 2009 MIMAKI ENGINEERING CO.,LTD.
7.1.2 P.3
7.1.2 List of Error Messages
1
2
3
4
5
6
7
8
36C
ERROR 36-C
MARK DETECT
The mark cannot be detected.
(After the print media detection)
Check the followings.
• Media curling
• Specified location for starting the mark detec-
tion.
• Is the black mark printed on the white back-
ground of the media?
• Aren’t there any unnecessary prints or blots and
adhesion of dirt inside the marks?
• Aren’t there any errors in each setting of the
mark?
ERROR 36-C
JOG & <ENT>or<END>
The mark cannot be detected.
[MARK DETECT] and [JOG & <ENT>or<END>]
are alternately displayed during the copying and
cutting of the mark.
During this error, the write pointer stops at the start-
ing point for the mark detection.
In case the write pointer position is not in the right
place for starting the mark detection, make a posi-
tion adjustment using the [JOG] key and restart the
mark detection by pressing [ENTER]. And also
check the followings.
• When using a limp media which is lacking in
elasticity or whose width is more than about
800 mm, increase the number of pinch rollers
used.
• When using the limp media, adjust the size of
the mark at 8 mm or more on a side, and allo-
cate the marks to be copied 8 mm or more apart
from each other.
• Is the black mark printed on the white back-
ground of the media?
• Aren’t there any unnecessary prints or blots and
adhesion of dirt inside the marks?
• Aren’t there any errors in each setting of the
mark?
• Since the media may be floated by the use of the
media holder, carry out the mark detection with-
out using it.
37C
ERROR 37-C
MARK ORIGIN
As a result of the mark detection, the origin was
detected outside the usable plot area.
Arrange the marks within the usable plot area.
38C
ERROR 38-C
MARK SCALE
The mark cannot be detected.
[MARK SCALE] and [JOG & <ENT>or<END>]
are alternately displayed during the copying and
cutting of the mark.
(Refer to ERROR 36-C “JOG &
<ENT>or<END>”)
40
ERROR 40
MOTOR ALARM X
Excessive load to the X-motor. Turn off the main power, and turn it on a little later.
If the error occurs again, carry out the followings.
1. Check friction of X (Y) -axis motor.
2. Check if media attaches on the platen.
Media Attachment to the Platen ( See 7.2.2 ).
3. Replace the X (Y)-axis motor.
4. Replace the regenerative resistivity PCB assy.
(See 6.5.2)
5. Replace the main PCB assy. (See 3.4.1)
41
ERROR 41
MOTOR ALARM Y
Excessive load to the Y-motor.
42
ERROR 42
X OVER CURRENT
Over current error of X-motor is detected.
43
ERROR 43
Y OVER CURRENT
Over current error of Y-motor is detected.
45
ERROR 45
CAPPING : PARAMETER
An error occurred in capping control.
(Improper parameter adjusted value)
Turn off the main power, and turn it on a little later.
If the error occurs again, carry out the followings.
1. Make sure that the adjusting value of
[#ADJUST] -> [CAPPING] is set correctly.
List of error messages (3/6)
Error
No.
Indication on LCD Cause Remedy
R.1.2
Maintenance Manual > Troubleshooting > Details on Errors and Malfunctions > List of Error Messages
Model CJV30/TPC Issued 2008.08.04 Revised 2008.12.06 F/W ver. 1.20 Remark
1.2
To Next Page
