MIMAKI CJV30 Series User Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
8.3.2 P.2
8.3.2 SETUP
1
2
3
4
5
6
7
8
[FUNCTION],
[] / []
[CUT1]MEDIA TYPE
TYPE :STANDARD
[CUT1]
MEDIA TYPE <ent>
:HEAVY
[FUNCTION],
[] / []
[CUT1]SORTING
SETUP :OFF
[CUT1]
SORTING <ent>
:ON
[CUT1]SORTING
AUTO FEED :OFF
:ON
[CUT1]SORTING
AREA :OFF
:10 to 5100
[FUNCTION],
[] / []
[CUT1]ADJ-PRS OFFSET
OFFSET = 3
[CUT1]
ADJ-PRS OFFSET <ent>
:0 to 7
[FUNCTION],
[] / []
[CUT1]WINDER TIMMING
SETUP :OFF
[CUT1]
WINDER TIMMING <ent>
:OFF
:1 to 99
[FUNCTION],
[] / []
[CUT1]OVER CUT
LENGTH : 0.1mm
[CUT1]
OVER CUT <ent>
:OFF
:0.1 to 1.0
[FUNCTION],
[] / []
[CUT1]SETUP COPY
CUT1 -> CUT2
[CUT1]
SETUP COPY <ent>
CUT1 to 3
PEN
HALF
ALL
[CUT1]SETUP RESET
RESET :ent
[CUT1]
SETUP RESET <ent>
*Except when “PEN” is selected
[ON]: To the next screen
[FUNCTION],
[] / []
[CUT1]VACUUM
SETUP :STRONG
[CUT1]
VACUUM <ent>
:OFF
:WEAK
:LittleWEAK
:STANDARD
COPY : ent
CUT1 -> CUT2
Start of copying
[FUNCTION],
[] / []
[HALF]HALF CUT
SETUP :OFF
[HALF]
HALF CUT <ent>
:ON
[HALF]HALF CUT
HALF CUT PRES.= 0g
:0 to 300
[HALF]HALF CUT
HALF LENGTH = 0.5mm
:0.1 to 5.0
[HALF]HALF CUT
CUT LENGTH = 10mm
:5 to 150
[FUNCTION],
[] / []
[[CUT1]UP SPEED
SETUP :AUTO
[CUT1]
UP SPEED <ent>
:5cm/s
:10cm/s
:20cm/s
:30cm/s
When HALF is
selected
[CUT1]DUMMY CUT
SETUP :OFF
[CUT1]
DUMMY CUT <ent>
:ON
[FUNCTION],
[] / []
*Except when “PEN” is selected
[FUNCTION],
[] / []
[CUT1]DIVISION CUT
SETUP :OFF
[CUT1]
DIVISION CUT <ent>
:ON
[CUT1]DIVISION CUT
FRAME CUT :OFF
:ON
[CUT1]DIVISION CUT
MARK CUT :OFF
:ON
[]/[]/ [ON]:To the next screen
[FUNCTION],
[] / []
R.1.2
Maintenance Manual > Operation Flow > Cut Mode > SETUP
Model CJV30/TPC Issued 2008.08.04 Revised 20010.10.29 F/W ver. 2.50 Remark
1.2
Rev.

MIMAKI CJV30 Series Specifications

General

Cutting Function	Yes
Interface	USB 2.0, Ethernet
Power Supply	AC 100-240 V, 50/60 Hz
Print Head	Piezoelectric Inkjet
Resolution	1440 dpi
Print Resolution	Maximum 1440 dpi
Printing Technology	Solvent Inkjet
Print Speed	Up to 17.5 m²/h
Ink Type	Solvent Ink
Ink Colors	CMYK, White
Maximum Print Width	1610 mm (CJV30-160 model)
Media Width	1372 mm (54 inches)
Media Thickness	Maximum 1.0 mm
Cutting Force	500 g
Weight	180 kg (CJV30-160 model)
