MIMAKI JV3-160SP - CHAPTER 1 OVERVIEW OF MAINTENANCE

- 9 -
Where to Install the Device
Secure a suitable installation space before assembling the device.
The place of installation must have space required not only for the device itself but also for plotting
operation.
Model Width Depth Height Gross weight
JV3-160SP 2660 mm 750 mm 1240 mm About 175kg*
*: With exhaust unit : 185kg
0
m


500 mm
1000 mm
1000 mm
2640 mm
500 mm
