Specifications
Machine specifications
Item Specifications
Print head
Method Drop-on-demand piezoelectric print heads
Specification 4 heads: 2-layered staggered arrangement in 2-line
Drawing mode
(scan x feed)
Single-layer
300x600:Bi/Uni 2
*1
/ 4/ 6/ 8 pass (only normal mode)
300x900:Bi/Uni 6/ 8/ 12/ 16 pass (only normal mode)
600x900:Bi/Uni 12/ 16/ 24 pass
900x1200
*2
:Bi/Uni
16/ 22/ 32 pass
Two-layers
600x600:Bi/Uni 6/ 8/ 12/ 16 pass
600x900:Bi/Uni 12/ 16/ 24 pass
Usable inks LUS-120 ink (M,C,Y,K)
Ink supply Supplying 3L x 4 bottles
Capacity of ink tank 3L-bottle x 1 for each color
Media type PVC film/ tarpaulins/ FF
Max. printing width 3200mm
Roll Media size
Maximum 3250mm (
1524 mm each when twin rolls are set. 1620 mm when roll holders are used.
)
Minimum 210mm
Thickness 1 mm or less
Roll outside diameter When using take-up unit and feeding unit:Φ250mm or less
Roll weight
*3
When using feeding unit:100kg or less
When using roll holder:18kg or less
Roll inside diameter
When using take-up unit and feeding unit:3 inches
When using roll holder:2 or 3 inches
Printing surface Regardless of inside and outside
Roll end treatment
The roll end is gently fixed to the core with weak-adhesive tape or weak glue
for easy removal.
Leaf media size
Maximum 3250mm
Minimum 210mm
Margin
Leaf media
Left end and right end : 15 mm (Default) Front : 1400 mm Rear : 1300
mm
Roll media
Left end and right end : 15 mm (Default) Front : 1600 mm Rear : 1300
mm
Distance accuracy Reproducibility Whichever the larger one of ± 1.5 mm or ± 0.3 % of the designated
*4
*5
*6
Perpendicularity ± 0.5 mm / 1000 mm
Media skew 5 mm or less / 10 m variable
Head height adjustment 1.7, 1.9, 2.6, 3.3 mm
Media delivery
Take-up device supplied as a standard accessory
(switching possible between face in and face out
*7
).
Waste ink tank Tank type (10 liter)
Interface USB 2.0
Command MRL V
Noise
*8
during standby Less than 58 dB (FAST-A, Front & Rear & Left & Right 1 m)
during continuous print-
ing
Less than 65 dB
during discontinuous
printing
Less than 70 dB
Power AC200 - 240 ± 10% , 50/60Hz ± 1Hz , 15A or less
Power consumption 3.6KW or less
Recomended
Environment
Available temp. 20 °C to 30 °C (68°F to 86°F)
Humidity 35 to 65% Rh (No condensation)
Guaranteed temp. 20 °C to 25 °C (68°F to 77°F)
Temperature change ± 10 °C / h or less
Dust 0.15mg/m
3
(Equivalent to normal office level)
Highest operation
height
2000 m
