MIMAKI UCJV300 Series Care And Maintenance

TABLE OF CONTENTS
2
Maintenance
1. Maintenance Precautions ........................................................... 4
2. Maintenance Items and Timing................................................... 5
Items Required for Maintenance........................................................... 5
3. Maintenance Procedure.............................................................. 6
Ink Maintenance ................................................................................... 6
Wiper Cleaning ..................................................................................... 6
Cap Rubber Cleaning ........................................................................... 8
NCU Cleaning....................................................................................... 9
Carriage Underside Cleaning ............................................................. 10
Cleaning the Mist Filter ....................................................................... 11
Ink Discharge Channel Cleaning ........................................................ 12
Media Sensor Cleaning ...................................................................... 13
Media Holder Cleaning ....................................................................... 14
Jam Sensor Cleaning ......................................................................... 14
Platen Cleaning .................................................................................. 15
Cover (Exterior) Cleaning ................................................................... 16
When Not in Use for Extended Periods .............................................. 16
4. Consumable Item Replacement ............................................... 19
Wiper Replacement ............................................................................ 19
Cap Absorber Replacement ............................................................... 20
Mist Filter Replacement ...................................................................... 21
LED Glass Replacement .................................................................... 22
Exhaust Fan Filter Replacement ........................................................ 23
Pinch Roller Replacement .................................................................. 24
Media Holder Replacement ................................................................ 25
Media Cutter Replacement ................................................................. 27
Waste Ink Tank Replacement............................................................. 28
About the Media Cutter....................................................................... 31
Pen Line Replacement ....................................................................... 32

MIMAKI UCJV300 Series Specifications

General

Print Technology	UV-LED inkjet
Max Print Resolution	1200 x 1200 dpi
Power Supply	AC 100-240 V, 50/60 Hz
Ink Type	UV-curable ink
Media Thickness	1 mm or less
Interface	USB, Ethernet
Operating System Compatibility	Windows 10, Windows 8.1, Windows 7
Ink Colors	CMYK, White, Clear
