2. Maintenance Items and Timing
5
2. Maintenance Items and Timing
Timing Item
At the end of the work
day
Clean the wiper and wiper bracket. "Wiper Cleaning"(P. 6)
Clean the wiper cleaner. "Wiper Cleaning"(P. 6)
Clean the cap rubber. "Cap Rubber Cleaning"(P. 8)
Clean the NCU. "NCU Cleaning"(P. 9)
Clean the underside of the UV-LED lamp. "Carriage Underside
Cleaning"(P. 10)
Clean the underside of the carriage. "Carriage Underside Cleaning"(P. 10)
Mist filter 1
Soak up ink with a paper towel. "Cleaning the Mist Filter"(P. 11)
Clean the media sensor. "Media Sensor Cleaning"(P. 13)
Clean the jam sensor. "Jam Sensor Cleaning"(P. 14)
At the end of the work
week
Ink pad in the waste ink holder under the wiper
Soak up ink with a paper towel. "Wiper Cleaning"(P. 6)
Mist filter 2
Soak up ink with a paper towel. "Cleaning the Mist Filter"(P. 11)
Clean the ink discharge channel. "Ink Discharge Channel Cleaning"(P. 12)
Clean the platen. "Platen Cleaning"(P. 15)
Clean the cover (exterior). "Cover (Exterior) Cleaning"(P. 16)
Check the waste ink levels in the waste ink tank.
When noticeably dirty Replace with new exhaust fan filter. "Exhaust Fan Filter
Replacement"(P. 23)
Replace the exhaust fan box.
When not used for
more than a week
Clean the wiper and cap and wash the ink discharge channels. After cleaning,
store without turning off the main power supply. "When Not in Use for
Extended Periods"(P. 16)
Periodically Shake the Ink bottle. "Ink Maintenance"(P. 6)
Items Required for Maintenance
To order replacement consumable items, contact your local dealer or our service office.
For more information on consumable items, refer to our website. https://mimaki.com/supply/inkjet.html
• Avoid storing this product in locations accessible to children.
