AS3000™ Service Manual 0070-10-0683 4 - 11
Replacement Parts and Accessories Isometric Drawings
4.3.2.1 Breathing System Parts List
FIG. NO. DESCRIPTION PART NUMBER
32 Common Gas Outlet Assembly 0997-00-0633
33 O
2
Sensor 0600-00-0149
34 Airway Pressure Gauge 0118-00-0038
35 Bag Arm Tall 0009-00-0013
36 APL Valve 0104-00-0065
37 Absorber Canister Assembly 0997-00-0629 (original)
115-005724-00 (revised)
38 Breathing System Pneumatics Hose 082-000387-00
39 Breathing System Support Arm 0436-00-0253
40 O
2
Sensor cable 0012-00-1775
41 Cable, Heater 0012-00-1780
42 Drive Gas Hose 0004-00-0098
43 AGSS Transfer Hose 0004-00-0095
44 O
2
Sensor Interface 0198-00-0080
45 O Ring, 6 x 1.8 0354-00-0188
46 O Ring, 4 x 1.8 0354-00-0189
47 Ring, I/E Valve 0219-00-0018 (plastic)*
0219-00-0020 (metal)*
48 Cover, I/E Valves 0352-00-0068
49 Gasket, I/E Valves 0354-00-0192
50 Frame, I/E Valve 0352-00-0069
51 Disc, Ceramic I/E Valve 0354-00-0182
52 O
2
Port Plug 0198-00-0083
53 Cover, Bellows 0198-00-0079
54 Bellows Assembly 115-005968-00
55 Gasket, Bellows Canister base 0354-00-0191
56 Absorber Hose 0004-00-0097
57 Absorber Mount Assembly 0436-00-0256
58 Absorber Gasket 0354-00-0199 (original)
047-002849-00 (revised)
59 Canister, Soda Lime 0352-00-0070 (original)
045-000254-00 (revised)
60 Absorber Screen, Metal 0378-00-0073
61 Absorber Canister Gasket 0354-00-0183 (original)
045-000252-00 (revised)
047-002850-00 (revised)
NS Bag Arm Short 0009-00-0012
NS Bellows Support Cage 082-000389-00
NS Alignment Bracket Kit 115-007641-00
NS Not Shown
* Parts are not one-to-one interchangeable.
