Ventilator Control and Drive Theory of Operation
1 - 20 0070-10-0683 AS3000™ Service Manual
1.5.1.3 PAW Pressure Sensor Board
FIGURE 1-12 Paw Pressure Sensor Board, Top View
FIGURE 1-13 Paw Pressure Sensor Board, Bottom View
Paw Board
Paw, J2
PIN NAME FUNCTION
1. AGND Analog Ground
2. Paw Pressure inside airway
3. AR5V 5V
4. NC No connection
5. NC No connection
