Ventilator Control and Drive Theory of Operation
1 - 24 0070-10-0683 AS3000™ Service Manual
Sensor Board
Pair, J1
PIN NAME FUNCTION
1. AGND Analog Ground
2. Pair Pressure of air
3. NC No connection
4. AR10V 10V
5. NC No connection
PAW, J2
PIN NAME FUNCTION
1. AGND Analog Ground
2. Paw Pressure inside airway
3. AR5V 5V
4. NC No connection
5. NC No connection
Work Light Power, J11
PIN NAME FUNCTION
1. 24V Power 24V
2. GND Power Ground
Backlight Power, J15
PIN NAME FUNCTION
1. 24V Power 24V
2. GND Power Ground
Switch of Gas Supply, J6
PIN NAME FUNCTION
1. GND Ground
2. NC No connection
3. Pgas Switch input
Expire Valve, J14
PIN NAME FUNCTION
1. 5V 5V
2. Valexp Expire Valve Drive
