Mindray DP-50 User Manual

4-4 Exam Preparation
Exam Type
Information
Description
GYN
(Gynecology)
LMP
Last menstrual period
Gravida Times of pregnancy.
Para
Times of delivery
Ectopic Times of abnormal pregnancy. e.g. extrauterine pregnancy
Aborta
Times of abortion
CARD
(Cardiac)
Height /
Weight
/
BSA (body
surface
area)
After the height and weight are inputted, the system will
automatically calculate the BSA based on the formula which
is set via [Setup] -> [System Preset] ->[General].
BP Blood pressure.
HR
/
RA Press
Right Atrium Pressure
VAS
(Vascular)
BP(L) Input left blood pressure.
BP(R)
Input right blood pressure.
URO
(Urology)
Serum PSA /
PPSA
coefficient
/
SMP (Small
Parts)
None /
PED
(Pediatrics)
None /
3. Operating Information
 Ref. Physician: the people who requires the operator to do the ultrasound operation.
“\”, “^”, “＝” and “,” are not permitted.
 Diagnostician: people who is responsible for exam. “\”, “^”, “＝” and “,” are not
permitted.
 Operator: people who is responsible for images collection and scanning. “\”, “^”, “＝”
and “,” are not permitted.
 Accession #: exam number used in DICOM, “\” is not permitted.
 Comment: exam-specific explanation or remarks.
4. Functional key
 [New Patient]: click to clear the current patient information in the patient information
screen in order to input new patient information.
 [New Exam]: click to clear the current exam information in order to create a new
exam for the current patient.
 [Pause Exam]: to pause the current exam.
 [Cancel Exam]: to cancel the current exam.
 [OK]: click to save the patient data entered and exit the screen.
 [Cancel]: click to cancel the patient data entered and exit the screen.

Mindray DP-50 Specifications

General

Transducer Ports	2
Cine Loop	Yes
Type	Portable Ultrasound System
Probes	Convex, Linear
Connectivity	USB, DICOM
Power Supply	100-240V~ 50/60Hz
Applications	Obstetrics, Gynecology, Urology, Cardiology
