4 Setup
Operator’s Manual 4 - 33
• IP address should be the address of the remote server.
DICOM local preset items are described as follows:
Adding a Server
Perform the following procedure:
1. Enter the server device name and IP address.
2. Click [Ping] to check the connection.
3. Click [Add] to add the server to the device list, and its name and address are displayed in the
list.
Item Description
Local host
DICOM
Service
Property
(Including
SCU and
SCP)
AE Title Application Entity title.
Port Communication port, DICOM communication port.
PDU Maximum PDU data package size (not need to change),
ranging from 16384 to 65536; if the value is less than 16384
or greater than 65536, the system automatically sets it to the
value 32768.
Resume tasks upon
restart
Resume unfinished sending tasks after system reboot.
Max The maximum number of tasks that can be resumed.
TLS Port Set the TLS port.
TLS Server Setting Import the encryption key/certificate.
TLS Client Setting • After importing TLS certificates, and selecting Verify
Certificate check box, the system verifies the
effectiveness of the TLS function in the DICOM storage,
print, and worklist services.
• Import trusted certificates, or delete certificates.
Server
Setting
Device Name of the device supporting DICOM services.
IP Address IP address of the server.
Ping You can ping the other machines after you entered the
correct IP address.
Besides, you can select a server in the Device list to ping it.
Add Click to add server (s) to the Device List.
Device List Displays the added device.
Delete Click to delete the selected server (s) in the device list.
Set DICOM Service Provides server settings of DICOM service. For details,
please refer to the following chapters.
Set DICOM Strategy Provides strategy settings of DICOM service. For details,
please refer to the following chapters.
Log Level Select the log display level: No Log, Service Result Log,
Service Process Log, All Log.
To Next Page
