A Barcode Reader
Operator’s Manual A - 7
A.2 2D Barcode Reader (Take DS4308 as an
example)
The 2-D barcode reader supports hand-held operation mode.
Hand-held mode: press the trigger to decode.
A.2.1 Overview
A.2.2 Setting Up the Digital Imager Reader
Installing the Interface Cable
1 LED • Green: A barcode was successfully decoded.
• Red: A data transmission error or reader malfunction occurred.
2 Scan window Scan the barcode.
3 Trigger Press to decode.



