System Overview 2-11
No. Name Description Function
10 F1
User-defined
key
You can assign a function to the key.
11 Biopsy / Press to show or hide the biopsy guide line.
12 Setup / Press to open/close the setup menu.
13 Del / Press to delete the comment, etc.
14 /
Alphanumeric
keys
Same as on PC
15 Dual
Dual-split
screen
Press to enter Dual mode from non-Dual mode;
Press to switch between windows in Dual mode.
16 Quad
Quad-split
screen
Press to enter Quad mode from non-quad mode;
Press to switch between windows in Quad mode.
17 Steer
/ Press to activate the steer function for linear
probe.
18 /
Direction key
To adjust LCD brightness or contrast when
pressing with <Fn> key.
19 Cine / Press to enter or exit the cine review status.
20 Body Mark / Press to enter or exit the Body Mark status.
21 Arrow / Press to enter or exit the arrow comment status.
22 Clear
/ Press to clear the comments or measurement
calipers on the screen.
23 Scale / Press to adjust image parameter of Scale.
24 Baseline / Press to adjust image parameter of Baseline.
25
Menu Nav.
/
Multifunction button
26 / /
To adjust the image parameter combed with the
key of Scale/Baseline/Nav.Rot
27 3D/4D / Press to enter or exit the 3D/4D status.
28 Cursor / Press to show the cursor.
29 / Trackball Roll the trackball to change the cursor position.
30 Set /
Press to confirm an operation, same as the left-
button of a mouse.
31 PW / Press to enter PW mode
32 Color / Press to enter Color mode
33 M / Press to enter M mode
34 B / Press to enter B mode
35
Measure
/
Press to enter/ exit Application Measurement
36 Update /
Measurement status: press to switch between the
fixed and active end of the caliper;
Multi-imaging mode: press to change the
currently active window.
iScape: press to start/stop image acquisition.
