5-22 Image Optimization
5.9.2 Exit Color M Mode
 Press <Color> or <M> on the control panel to exit Color M mode.
 Or, press <B> on the control panel to return to B mode.
5.9.3 Color M Mode Image Parameters
 In Color Flow M mode, parameters that can be adjusted are in accordance with those in B,
M and Color modes; please refer to relevant sections of B, Color and M mode for details.
 In Color Tissue M mode, parameters that can be adjusted are in accordance with those in
B, M and TVI modes; please refer to relevant sections of B, M and TVI mode for details.
 ROI Adjustment
ROI determines the size and position of the color flow or color tissue displayed in the
Color M mode image.
 Set the position of the sampling line by moving the trackball left and right, and set the
ROI position by moving the trackball up and down.
 Set the ROI size by moving the trackball up and right.
 Press <Set> to switch the cursor status between the ROI position adjustment and
ROI size adjustment.
5.10 Anatomical M Mode (Free Xros M)
CAUTION:
Anatomical M Mode and Color Anatomical M mode images are
provided for reference only, not for confirming a diagnosis. Please
compare the image with that of other machines, or make diagnosis
using none-ultrasound methods.
For an image in the traditional M mode, the M-mark line goes along the beams transmitted
from the probe. Thus it is difficult to obtain a good plane for difficult-to-image patients that
cannot be moved easily. However, in the Anatomical M mode, you can manipulate the M-mark
line to move to any position at desired angles. The system supports anatomical M scanning
(including Free Xros M mode) in 2D imaging modes (B, Color, Power and TVI mode).
 Shortcut key setting
You can preset a user-defined key for entering Free Xros M mode: [Setup] -> [System
Preset] -> [Key Config], Refer to “12.1.6 Key Config” for details.
 Free Xros M Imaging Procedures
1. In real-time 2D mode or M mode, adjust the probe and image to obtain the desired plane.
Or select the desired 2D cine files.
2. Click [Free Xros M] on the image menu of the B mode to enter Free Xros M mode, or
press the user-defined key.
3. Adjust the M-mark line to obtain optimized images and necessary information.
 In Dual-split or Quad-split mode, it is the current activated window that enters the Free
Xros M mode.
Free Xros M imaging is supported on frozen B image, B+M image and B+Power/Color/TVI
image.
