SPM address Type of data R/W Function
B7
X56
X57
X58
X59
X60
BYTE
BOOL
BOOL
BOOL
BOOL
BOOL
R
R
R
R
R
R
Active status
Test mode active
Calibration active
Instrument is tared
Pendeo only: no standstill
Pendeo only: operation with a simulated LC
X64 BOOL R/W Standard application only: Read/write marker bit 1
X65 BOOL R/W Standard application only: Read/write marker bit 2
X66 BOOL R/W Standard application only: Read/write marker bit 3
X72 BOOL R/W Switch D11 to net weight.
X112 BOOL W Zero device.
X113 BOOL W Tare device
X114 BOOL W Reset the tare of the instrument
X115 BOOL W Start the test mode
X116 BOOL W Finish the test mode
X117 BOOL W Reset the power fail signal
X118 BOOL W Set the preset tare value as tare
X119 BOOL W Act. Store the gross weight in the preset tare memory (D31)
X121 BOOL W Reset error B19 = 0.
B16 USDINT R Exponent
Number of decimals
Example: 1.23 is displayed
Exponent: 2
B17 USDINT R Weight unit 1 = mg, 2 = g, 3 = kg, 4 = t, 5 = lb, 9 = oz
B18 USDINT R Scale interval (multi-interval/multiple range = d1 or e1)
B19 BYTE R Last weighing point error, see Chapter 16.6.1.
B20 BYTE R Higher byte of product code (0x54)
B21 BYTE R Lower byte of product code (0x10)
B22 BYTE R Major part of version number (1.0)
B23 BYTE BYTE Minor part of version number (1.0)
D6 UDINT R Serial number (board number)
W14 INT R Counter will be increased for every measured value.
D8 DINT R Current gross weight
D9 DINT R Current net weight
13 SPM Transmitter Series PR 5220
EN-213 Minebea Intec
