Minebea Intec PR 5220/06 User Manual

[Indicator]
Displays the weighing point in a status window, see Chapter 9.2.2.
[Indicator pop-up window]
Displays the weighing point in a status window, see Chapter 9.2.2.
[Conguration printout]
Display conguration printout, saving and printing out as a text le, see Chapter 9.2.3.
[Log les]
Display logles, saving and printing out as a text le, see Chapter 9.2.4.
[Screenshot]
Displaying, saving and printing a screenshot, see Chapter 9.2.5.
[Show error Log]
Display and save the error logs, see Chapter 9.2.6.
[Backup of Earom]
Saving and restoring the conguration and calibration data, see Chapter 9.2.7.1.
9.2.2 Displaying weighing points in a table
9.2.3 Conguration printout
With the [Conguration Printout] menu item the conguration of the device of the device
can be displayed, saved and printed out.
1. Click on the [Indicator] menu item in the WEB menu.
A status window opens in which the weight of the weighing point is displayed
with unit and the status symbols.
2. Click on the symbol in the Internet browser to return to the WEB menu.
3. Click on the [Indicator Pop-up Window] menu item in the WEB menu.
A separate status window opens in which the weight of the weighing point is
displayed with unit and the status symbols.
4. Click on the symbol to return to the WEB menu.
1. Click the [Conguration Printout] menu item in the WEB menu.
9 Extended functions Transmitter Series PR 5220
EN-175 Minebea Intec
