Data type Description Value range
LWORD bit-sequence 64 …
13.3 Addressing
The SPM table can be addressed via dierent counts. Bit addressing is used to count the
individual bits (MX). Byte addressing is used to count individual bytes (MB), whereby,
e.g.bits MX0MX7 are identical to byte MB0.
Code Data type Address example
%ML LWORD L21
%MD DINT
D4243
%MW WORD
W8487
%MB BYTE
B168175
%MX BOOL (bit)
X13441407
13.4 System data
SPM address Type of data R/W Function
X0X2
BOOL R
Digital input 13
X810
BOOL R
Digital output 13
X1618
BOOL R
Standard application only: Output limit 13
B4
X32
X33
X34
X35
X36
X37
X38
X39
BYTE
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
R
R
R
R
R
R
R
R
R
Indicator status
ADC error
Above max. (FSD)
Above max. + still permissible range (OVL)
Below zero
Zero ±¼ d
Within the zero setting range (ZSR)
Weight is stable
The weight is below zero or above max. (FSD)
B5
X40
X41
X42
X43
X44
BYTE
BOOL
BOOL
BOOL
BOOL
BOOL
R
R
R
R
R
R
ADC status
Measuring signal negative (error 7)
Measuring signal >36 mV (error 3)
Internal arithmetic error; CAL data are perhaps faulty (error 1)
No or too low sense voltage (error 6)
No communication with xBPI scale (error 9)
B6
X48
X49
X50
BYTE
BOOL
BOOL
BOOL
R
R
R
R
Command status
Command error
Command active
Mains failure signal
Transmitter Series PR 5220 13 SPM
Minebea Intec EN-212
