— Service The service window for the load cells is
displayed. No change is possible!
— Limit 13 on
Enter 0 – Max (maximum load); take unit from
calibration.
— Action
Action, selection: no action, set marker 13, clr
(clear) marker 13
— Condition Condition, selection: see Chapter 7.15.5.
— Limit 13 o
Enter 0 – Max (maximum load); take unit from
calibration.
— Action
Action, selection: no action, set marker 13, clr
(clear) marker 13
— Condition Condition, selection: see Chapter 7.15.5.
— Output 1…3 Congure outputs, selection: see
Chapter 7.15.7.
— Input 1…3 on Congure inputs
— Action Action, selection: see Chapter 7.15.6.1.
— Condition Condition, selection: see Chapter 7.15.6.2.
— Input 1…3 o Congure inputs
— Action Action, selection: see Chapter 7.15.6.1.
— Condition Condition, selection: see Chapter 7.15.6.2.
— Analog mode Analog output parameter: Gross D08 = gross,
Net if tared D09 = Net if tared, Selected D11 =
value on the display, Transparent D30 =
Transparent, no output = analog output
unused, see Chapter 7.15.8.
— Analog range
Output range: 020 mA, <420 mA>
— Output on error Output on error: 0 mA = set to 0 mA, <4 mA> =
set to 4 mA, 20 mA = set to 20 mA, hold = last
output value remains unchanged
— Output if <0
7.11.6 Limit parameter
Note:
This menu item is only available if under -[Operating parameter]- [Application]
"Standard" has been selected.
7.11.7 Digital I/O parameters
Note:
This menu item is only available if under -[Operating parameter]- [Application]
"Standard" has been selected.
7.11.8 Analog output parameter
7 Commissioning Transmitter Series PR 5220
EN-73 Minebea Intec
