Minebea Intec PR 5220/06 User Manual

Note:
See Chapter "Description of the I/O Area"
Example:
The gross weight should be read.
I/O size = 8 bytes, counted from byte 0–7
7.15.3.4 EtherNet-IP settings for Rockwell workstation
Requirements:
- PR 5220/07 DeviceNet EtherNet-IP is installed.
Procedure:
Note:
Further details can be found in the supplementary application manual "How to"
(available upon request from technical.support.hh@minebea-intec.com).
Note:
See Chapter "Description of the I/O Area"
Example:
The gross weight should be read.
I/O size = 8 bytes, counted from byte 0–7
7.15.4 Network parameters
Under this menu item, you can dene the network parameters for the network
connections (built-in LAN adapter).
Open the menu via - [Network parameter].
5. Assign the instrument name to the PR 5220.
1. Enter the IP address and network mask under - [Fieldbus parameter] and
conrm.
2. Register the le "sag_5220_Ethernetip.eds" using the "Hardware Installation Tool".
3. Select and insert the instrument from the catalog into the I/O conguration.
7 Commissioning Transmitter Series PR 5220
EN-135 Minebea Intec
