17.4.2 Electromagnetic Compatibility (EMC)
All data corresponds to EN 61326 industrial section
High frequency electromagnetic elds
(801000 MHz)
EN 61000-4-3 10 V/m
High frequency electromagnetic elds
(1.42.0 GHz)
EN 61000-4-3 3 V/m
High frequency electromagnetic elds
(2.02.7 GHz)
EN 61000-4-3 1 V/m
Housing
Electrostatic discharge (ESD) EN 61000-4-2 6/8 kV
Fast transients (burst) EN 61000-4-4 1 kV
Peak voltages (surge) 1.2/50 µs EN 61000-4-5 1 kV
Signal and control
lines
Conducted disturbances by high fre-
quency coupling (0.1580 MHz)
EN 61000-4-6 10 V
Fast transients (burst) EN 61000-4-4 2 kV
Peak voltages (surge) 1.2/50 µs EN 61000-4-5 1/2 V
Mains inputs
Conducted disturbances by high fre-
quency coupling (0.1580 MHz)
EN 61000-4-6 10 V
17.4.3 RF interference suppression
Interference emission According to EN 61326, limit value class A, for
industrial sectors
17.5 Weighing electronics
The weighing electronics are suitable for connection of strain-gauge load cells.
17.5.1 Load cells
Load cell type DMS cells 6 or 4-wire connection possible
Supply voltage 12 V DC - for I
max
= 160 mA
- for max. 8 load cell with je 650 
- 4 load cells with 350  each
Sense voltage monito-
ring
Shortfall of +4 V DC -4 V DC is recogni-
zed. Can be turned o by software.
Max. load
≥75 
17 Specications Transmitter Series PR 5220
EN-227 Minebea Intec
